Alloy 330 Plates
Product Details:
- Surface Treatment Polished
- Alloy Yes
- Product Type Iron
- Grade Alloy 330
- Shape Other
- Thickness 4.8-22.4 Millimeter (mm)
- Application Industrial
- Click to View more
X
Alloy 330 Plates Price And Quantity
- 100 Kilograms
Alloy 330 Plates Product Specifications
- Yes
- 4.8-22.4 Millimeter (mm)
- Industrial
- Polished
- Gray
- Iron
- Alloy 330
- Other
Product Description
Available thicknesses for Alloy 330 plates
3/16 | 1/4 | 3/8 | 1/2 | 5/8 | 3/4 | 1 |
4.8mm | 6.3mm | 9.5mm | 12.7mm | 15.9mm | 19mm | 25.4mm |
Chemical Analysis
Nickel | 34.0 - 37.0 | Chromium | 17.0 - 20.0 |
Iron | Balance | Carbon | 0.08 max |
Silicon | 0.75 - 1.50 | Manganese | 2.0 max. |
Phosphorus | 0.030 max. | Sulfur | 0.030 max. |
Thermal and Electrical Properties
| Temperature | Thermal Conductivity | Electrical Resistivity | |||
| F | C | Btu-in/ft2M/-h-F | W/m-C | ohm-circ mil/ft | mW-m |
| 75 | 24 | 86 | 12.4 | 612 | 1.017 |
| 400 | 204 | 108 | 15.6 | 649 | 1.079 |
| 800 | 227 | 134 | 19.3 | 688 | 1.144 |
| 1200 | 649 | 162 | 23.4 | 721 | 1.199 |
| 1600 | 871 | 198 | 28.6 | 744 | 1.237 |
| 1800 | 982 | 216 | 31.2 | 749 | 1.245 |
Mechanical Properties
| Yield Strength | Ultimate Tensile | Elongation | Hardness | ||
| ksi | (MPa) | ksi | (MPa) | % | Rockwell B |
| 30 - 43 | 207 - 296 | 80 - 85 | 552 - 586 | 40 - 45 | 70 - 85 |
